Tandem 8ft by 5ft


The Loader - Tandem axle 8ft x 5ft braked trailer.

Tandem Trailers are strong, robust and reliable with additional capacity.

It's user-friendly for builders' sheets, GIB board and ride-on mowers.

The 8x5ft Tandem Trailer braked has a 2000kg payload.

It ticks all the boxes at a great price point.

This tandem axle trailer is fully-welded, not bolted together, has a 2.5mm checker plate floor and sides, and wraps up the sides, giving additional strength.

This model has lights on the outer edges, allowing the trailer to have even longer loads and drive with the front and rear tailgates lowered. Other retailers have trailers that can't drive with gates lowered as the gate hits the cage.

Assembled with care by our team in NZ. Perfect for transporting various items: furniture shifts, garden clearance, tip trips, sports gear etc.

- Tow bar braking system for enhanced braking ability and safety
- Heavy duty capacity of 2000kg – pile it up high and heavy
- Side running boards and mudguards that you can stand on when loading
-Side and rear pipes for tie-downs
- 14" wheels for increased stability when towing

Make it versatile. Add these on as Extras:
- Removable cage (900mm) with rear swinging gate for loading.
- Removable tarpaulin frame
- Additional tow ball for trailers for bike rack addition
(See Extras for add-on pricing and information).

  • Lead time: Immediate
  • Pick-up locations available
  • Finance available
  • Assembled in NZ

Order Now:

30 in stock

30 in stock

Registration and 3 year WOF

Trailer Cage 8 x 5ft / 900mm

Trailer Cage 8 x 5ft / 600mm

Tarpaulin/Trailer Cover 8 x 5 trailer 900mm

Spare wheel

H Frame 5ft 900mm

H Frame 5ft 600mm

Ramp 5 foot wide


Towbar Trailer Lock

Tarp Installation

You can choose your pickup location at the checkout.


Technical Specifications

Axle Double axle / Tandem axle
Overall Dimensions (ft)
Overall Dimensions (mm)
Box Size (Internal) 8ft by 5ft (2438mm x 1524mm)
Draw bar length from the base of the tail gate
Full Welded Chasis
Tare Weight (Empty Trailer Weight) 500kg
Payload Capacity (Maximum Load Limit) 2000kg
ATM Weight 2500kg
Floor and Sides Construction 2.5mm checker steel plate with Standard 300mm Depth sides
Trailer Box Side Height 300mm
Steel Thickness 2.5mm
Surface Finish Hot-dipped galvanised steel
Tow Ball Coupler NZ and Australian standard 1 7/8"
50mm Coupling Can be supplied at extra cost
Safety Chains Standard 10cm
Dual Coupling Can be supplied at extra cost
Wheels & Tyres 165/70R-14 inch Tyre, Commercial
Braked Mechanical disc brake with handbrake function
Mudguards 2.55mm checker-plate with folding design function
Lights LED Lights
Reflectors Back of the trailer, red and orange
Electrical Details Electrical plug standard 7 pin plug
Jockey Wheel Included Yes
Tie Downs 4 full length tie down rails
H Frame Holders Yes
Hinged / Removable Tail Gates Yes
Leaf Springs 7 inch Slipper Leaf Spring
Axle Style Solid axle 50mm solid square axle
Full Welded Chassis


Bearing Savers NZ Standard bearings
Hydraulic Power Pack
Battery with solar charger or Anderson plug wired to car
Other features / details
Lead Time (when not in stock at location)

East Tamaki: Immediate
Hamilton, Riverhead: 24 hours
Kerikeri, Whangarei: 48 hours
Taupo, Tauranga, Whakatake: By Arrangement

Add-On Upgrades

Registration and 3-year WOF $160
Spare Wheel $199
Tarpaulin - 900mm $325
Cage - 900mm $450
Trailer Lock $25
Electric Braking Remote $n/a
Tarp Installation (1.5 hour install time) $70
Digger ramps installed $
Lockable Toolbox plus Installation $
Lockable Tool box large including Installation $180
H frames $425
Ramp - Mesh $525

Other Add-Ons Available

  • Mower bucket
  • Additional bike tow bar
  • Sliding doors


Warranty Full 3 year warranty

Stock Locations

East Tamaki Y
Riverhead Y
Whangarei Y
Kerikeri Y
Hamilton Y
Whakatane pick up orders only

Delivery Fee

East Tamaki None
Riverhead $50
Whangarei $175
Kerikeri $200
Hamilton $175
Whakatane $200
