Small Enclosed Trailer
$6,999.00
Our Small Enclosed Trailer has an external box size of 3050mm L x 1530mm W 1850mm H.
Internal Box: 3000mm L x 1480mm W x 1760mm H
This is a high-quality New Zealand-made, base-enclosed trailer ready to go.
You can add extras or modifications to this trailer. Or we can build a custom trailer from scratch to your design taste.
A strong and sturdy trailer ready-assembled by our team in New Zealand.
A great small single axle furniture trailer, enclosed and keeping your good dry and safe.
- Lead time: Immediately - we hold one all the time that is ready to go
- Pick-up locations available
- Finance available
- Assembled in NZ
- Specifically for Lucca trailers only
Order Now:
1 in stock
1 in stock
Technical Specifications
| Axle | 75 x 50 x 3 pre-galvanised chassis/axle |
| Overall Dimensions (mm) | 4350mm L x 2000mm W |
| Box Size (Internal) | External Box: 3050mm L x 1530mm W x 1850mm H | Internal Box: 3000mm L x 1480mm W x 1760mm H |
| Draw bar length from the base of the tail gate | |
| Full Welded Chasis | Yes |
| Tare Weight (Empty Trailer Weight) | 570kg |
| Payload Capacity (Maximum Load Limit) | 1230kg |
| ATM Weight | 1800kg |
| Floor and Sides Construction | 4mm ACM panel exterior, 12mm Trans-Tex 220 Ply floor |
| Trailer Box Side Height | |
| Frame | |
| Steel Thickness | 4mm plywood internal |
| Surface Finish | |
| Tow Ball Coupler | 1 7/8 standard |
| 50mm Coupling | |
| Safety Chains | |
| Dual Coupling | Can be supplied extra |
| Wheels & Tyres | 13" Wheel with 5x4.5" (5 stud Ford) stud pattern and 165R13c tires |
| Braked | None |
| Mudguards | External plastic |
| Lights | Multi-volt LED tall lights |
| Reflectors | Yes |
| Electrical Details | n/a |
| Jockey Wheel Included | Lucca Large 8" |
| Tie Downs | 1 x Rope rail 3 sides |
| H Frame Holders | n/a |
| Hinged / Removable Tail Gates | Ramp with gas struts |
| Leaf Springs | Eye/Slipper |
| Axle Style | 50 mm |
| Full Welded Chassis | Yes |
Other
| Bearing Savers | |
| Hydraulic Power Pack | |
| Battery with solar charger or Anderson plug wired to car | |
| Other features / details | |
| Lead Time (when not in stock at location) |
Other Add-Ons Available
Warranty
| Warranty | Full 3 year warranty |
Stock Locations
| East Tamaki | Yes |
| Riverhead | |
| Whangarei | |
| Kerikeri | |
| Hamilton | |
| Whakatane |
Delivery Fee
| East Tamaki | None. Call us to arrange. |
| Pukekohe | None. Call us to arrange. |
| New Plymouth | $350 |
| Hawkes Bay | $300 |
| Riverhead | None. Call us to arrange. |
| Whangarei | $200 |
| Kerikeri | $250 |
| Hamilton | $100 |
| Whakatane | $300 |
| Tauranga | $176 |
| Taupo | $176 |
| Rotorua | $175 |
